SSL Hardening for Web Application Proxy Servers

The Web Application Proxy (WAP) Servers act as an SSL termination instance towards the Internet. External connections that try to access the Active Directory Federation Services (ADFS) farm or internal applications that are published via the Web Application Proxy will terminate their SSL connections at the Web Application Proxy. Unfortunately, the Windows 2012R2 server default settings allow a lot of SSL Cipher Suites that are publically known as weak or “outdated” like SSLv3, DES encryption and key length below 128bit. The preferred Server Ciphers of a freshly installed and updated Windows 2012R2 server are SSLv3    168 bits        DES-CBC3-SHA TLSv1    256 bits        AES256-SHA Therefore from a network security standpoint it is mandatory to harden the SSL settings on the Web Application Servers BEFORE opening the WAP server in the DMZ for incoming Internet connections. The best option to harden the SSL settings on a standalone Windows Server 2012R2 is to modify the Local Group Policy: From a commandline run: “gpedit.msc”. In the computer section navigate to “Administrative Templates – Network – SSL Configuration Settings”  Edit the “SSL Cipher Suite Order”:

The listed Cipher suites can be exported and adjusted to the actual security requirements by deleting the unwanted Ciphers from the list. As a minimum all combinations that contain SSL2, SSL3, DES, 3DES, MD5 elements are deleted as well as all combination with a cipher length below 128bit.

Information

The list needs to be sorted in a way that the preferred SSL ciphers are on top.

Afterwards create a string of the values from list and separate each cipher by “,” without any blank. Don’t leave a “,” at the end of the string. The input box in the GPO menu has a limited size. Make sure that your string fits into this limit. If not, delete further ciphers which are not widely used.

Warning!

It looks like simply activating the new local GPO by running “gpupdate /force” is not sufficient. Please reboot the WAP servers one-by-one after setting the SSL cipher policy

However, before we open the firewall, an internal test should be executed to validate the SSL hardening. You can run the sslscan tool (you can download from here sslscan) from another computer in the DMZ or the WAP server itself. DNS resolving of the federation or application name must resolve to the external Load Balancer or interface of the WAP server. Example for SSL Server Ciphers before SSL Hardening (left side) and after SSL Hardening (right side):

When the Web Application Proxy server has been connected to the Internet finally, a second check can be achieved by using one of the proven Internet based SSL scan tools, e.g. https://www.ssllabs.com/ssltest/ .

You can find a string of the recommended SSL ciphers for importing into local GPO here.

Active Directory Federation Services 3.x Technology Basics

Active Directory Federation Services (AD FS) provides Web single-sign-on to authenticate a user to related external hosted Web applications. AD FS performs this by securely sharing digital identity and entitlement rights or claims across security and enterprise boundaries.

AD FS supports distributed authentication and authorization over the Internet to provide access to resources that are offered by trusted partners.

Another aspect of ADFS technology can be found in providing external access from Internet connections to internal resources. In that case the ADFS server can provide an additional layer of security by offering various pre-authentication methods, while the second part of the ADFS technology, the Web Application Proxy server (WAP) acts as a Reverse Proxy by terminating the incoming SSL connections.

In version 3.0 of the ADFS technology, the WAP server cannot be run without ADFS server in the backend, which stores the configuration of the WAP servers. The WAP servers themselves are “stateless” and therefore easy to scale up behind a Layer 4 Load Balancer.

ADFS Server Farms

The Active Directory Federation Services technology can be scaled out by deploying multiple ADFS servers in a farm model. The servers share the same configuration information which is stored in a database on each server (Windows Internal Database (WID) model) or in a central SQL store. In most of the implementations, the WID model is used.
For using the WID model, the configuration can only be modified on the Primary ADFS server and is then replicated to all other ADFS servers of the same farm.
To find the Primary Server use the command “get-adfssyncproperties” on one of the ADFS servers:

Web Application Proxy server

The Web Application Proxy Server is typically the Internet facing component of the Active Directory Federation Services technology. Located in the DMZ, the Web Application Proxy (WAP) servers act as reverse proxy server and terminate the incoming SSL connects from the Internet to the published applications.
Web Application Proxy servers are N to 1 connected to a specific ADFS server (farm). Multiple WAP servers can be easily configured for Layer 4 Loadbalancing.
Since WAP servers are “stateless”, they do not store any persistent configuration information, but load the information from the Primary ADFS server. Therefore a WAP server cannot exist without underlying ADFS server and needs to be installed after the ADFS farm has been deployed.

When acting as reverse proxy for client access using IWA (Integrated Windows Authentication) or when serving non claims aware application access based on Kerberos, the WAP servers must be able to perform Kerberos Constrained Delegation. The WAP server presents a Kerberos token on behalf of the accessing client or user, which in consequence requires the WAP server to be a member of an Active Directory domain. Unfortunately the domain membership of the WAP server means to open a lot more ports from the DMZ to the internal network, which is a disadvantage from network security perspective.

For that reason, applications that do not require Kerberos Constrained Delegation should always be published on non domain based WAP servers, where the exception is to publish applications on domain based WAP servers.

Example for ADFS Farm structure:

Notes Migrator for Exchange (NME) Version 4.12 released

Notes Migrator for Exchange Version 4.12 released

Dell published the Version 4.12 of the Notes Migrator for Exchange. The new features are:

  • Configurable Subject field for migrated meetings in resource calendars – Set the Subject field as the actual meeting Subject or the organizer of the meeting to mimic native Outlook behavior
  • Custom, string-based migration filters for Mail/Calendar items and address books – Limit the data pulled from the migrating NSFs using the Data Migration Wizard
  • Expanded time counters – The elapsed and remaining time counters have been expanded to correctly report migration runs longer than 24 hours
  • Configurable locale for target folder names — Specify which locale section (in its Task Parameters) to use when assigning folder names to Outlook folders

Since there has also been a lot of bugfixing in the new version, we recommend to update installations.

QMM 8.10 error: Agent is not ready to start – SCP not found

We used Quest Migration Manager 8.10 recently in a project at a customer for a combined Active Directory and Exchange migration. Overall target was to integrate a Windows 2003 domain cross forest and cross org into the central AD Forest with several child domains. Since from mail perspective our migration source was Exchange 2007 and our migration target Exchange 2013, we decided to use the Native Move Job option along with the Migration Manager for Exchange Agent (MAgE) services.

Situation:

The customer environment look like the following:
Source Domain in Single Domain Forest with Domain Controllers on Windows 2003 and Exchange 2007 as mail system.
Target Domain was one of several child domains in the central Forest. All domain controllers running Windows 2012 R2 and mail system was Exchange 2013 SP1.
All Exchange 2013 servers had been deployed to root domain which also kept all important system and admin accounts.
To limit complexity in the setup of Quest Migration Manager 8.10, we decided to use a single administrative account from target Forest’s root domain and granted all necessary permissions in the domains to run both, Active Directory and Exchange migration. Only for access to source Exchange 2007 when running the move request, we used an account from source domain with Org Admin permissions.

Native Move Job
Setup for Native Move Job

Installation of Migration Manager 8.10. on a member server in target domain (best practice recommendation) including all cumulative hotfixes went smoothly. After successful Directory Synchronization, we connected to the Exchange source and target Organization and finally deployed 2 Instances of the MAgE agent for native mailbox move jobs on our agent host and console server. Note: For agent hosts Windows 2012 R2 is currently (May 2014) not supported. You have to stay with Windows 2008 R2 here.

Problem:

However, after starting the agent services running with our administrative account , we recognized, that we could not open the log file of the agent in the Log Panel inside the Migration Manager for Exchange GUI. We searched for the log file and found it in “c:\progamdata\quest software\Migration Agent for Exchange\NativeMove directory”.

scp not found
Log snippet from MAgE agent

The log file showed that the agent was not starting to process the migration collection due to missing settings and then went to sleep. The lines of error:



Waiting for agent settings: Not found: (&(objectClass=serviceConnectionPoint) …..

Agent is not ready to start. Agent going to sleep at 1 minute.

repeated over and over.

Obviously the agent tried to execute an LDAP query to find a connection point in Active Directory.
Note: Currently QMM 8.10 uses 3 different systems to store configuration data: An ADLDS server, a SQL Server Instance and the Active Directory (ADDS).

Service Connection Point (SCP):

We ran the query which was shown in the log file against the target domain and we could find the Service Connection Point (SCP) immediately in the System container of the domain naming context.

QMM_8.10_SCP

The Service Connection Point consists primarily of the keywords array attribute and the serviceBindingInformation attribute. The QMM MAgE looks for the serviceBindingInformation attribute to get its SQL connection properties. In SQL it will finally find all information to process the collection.
QMM_8.10_SCP_3
We do not know why Developers at Dell Software made this process so complex. However, in our setup the agent could not find the Service Connection Point, because the agent was looking in the domain, where its service account was located and this was the root domain of the forest while the agent host had installed the SCP during installation in the child domain where the computer account was member of.

Solution:

Switching the agent host and agent service account to an account from child domain would have been a solution, but was not in compliance with customer policy to host all system accounts in root domain.
Moving agent host and console to root domain would not have meet best practices and would have interfered running directory synchronization.

So we ended up in giving the agent just what it requested:
We manually created a Service Connection Point in the root domain and copied all serviceBindingInformation values over.

The agent started immediately and worked without errors.

For future design we can only recommend to store Service Connection Point in the Configuration Partition as Exchange and lots of other software. Using the domain naming context will always lead to problems in a big Enterprise environment with Active Directory consisting of multiple domains in a  forest.
